Order of tables appear in the SQL generated by the MicroStrategy SQL Generation Engine


Order of tables appear in the SQL generated by the MicroStrategy



Most latest generation databases provide the same performance regardless of the order in which the tables are placed in the FROM clause SQL query. Their optimizers take care of choosing the most efficient way of performing the joins. Other databases perform differently producing a different order. This means that a database compiler may choose a different join path that can be more or less efficient.

By default, the MicroStrategy SQL Generation Engine orders the tables in the following way:
  1. Fact Tables
  2. Metric Qualification (MQ) Tables
  3. Relationship Tables
  4. Lookup Tables

But this behavior can be changed by using the 'From Clause Order' VLDB property under the 'Joins' folder. This setting has four values:


Below are the values that the setting may have:
  • Normal FROM clause order as generated by the engine
    This is the default value. It uses the following order:

    1. Fact Tables
    2. MQ Tables
    3. Relationship Tables
    4. Lookup Tables


  • Move last table in normal FROM clause order to the first
    This option moves the last table in the normal order (which is a lookup table) to the beginning of the From clause. This value is useful in some Oracle databases where it may be more efficient for the Fact table not to be the first table in the From clause.

  • Move MQ table in normal FROM clause order to the last (for Redbrick)
    This value orders the MicroStrategy SQL Generation Engine to place the MQ tables at the end of the FROM clause. So the order becomes the following:

    1. Fact Tables
    2. Relationship Tables
    3. Lookup Tables
    4. MQ Tables
  • Reverse FROM clause order as generated by the Engine
    This value reverses the normal order of tables as generated by the MicroStrategy SQL Generation Engine. So the order becomes the following:

    1. Lookup Tables
    2. Relationship Tables
    3. MQ Tables
    4. Fact Tables
Note: The "From Clause Order" VLDB property is intended to control syntax only, not join behavior. Report results should be the same for all values of this setting. If the report uses only inner joins, then the only thing that changes is the table order. One-sided outer joins will switch direction when the From clause order is altered.

For example, a report that performs left outer joins to lookup tables (using the "Preserve all final pass result elements" VLDB property) will generate SQL such as the following:

select   a11.REGION_ID REGION_ID,
   max(a14.REGION_NAME) REGION_NAME,
   a12.CATEGORY_ID CATEGORY_ID,
   max(a13.CATEGORY_DESC) CATEGORY_DESC,
   sum(a11.TOT_DOLLAR_SALES) WJXBFS1
from   STATE_SUBCATEG_REGION_SLS   a11
   left outer join   LU_SUBCATEG   a12
    on    (a11.SUBCAT_ID = a12.SUBCAT_ID)
   left outer join   LU_CATEGORY   a13
    on    (a12.CATEGORY_ID = a13.CATEGORY_ID)
   left outer join   LU_REGION   a14
    on    (a11.REGION_ID = a14.REGION_ID)
group by   a11.REGION_ID,
   a12.CATEGORY_ID
    Moving the last table to the top of the From clause places the joins for the first three tables in parentheses. LU_REGION, formerly last, now appears first and right outer joins to the parenthesized join expression.

    select   a11.REGION_ID REGION_ID,
       max(a14.REGION_NAME) REGION_NAME,
       a12.CATEGORY_ID CATEGORY_ID,
       max(a13.CATEGORY_DESC) CATEGORY_DESC,
       sum(a11.TOT_DOLLAR_SALES) WJXBFS1
    from   LU_REGION   a14
       right outer join       (STATE_SUBCATEG_REGION_SLS   a11
       left outer join   LU_SUBCATEG   a12
        on    (a11.SUBCAT_ID = a12.SUBCAT_ID)
       left outer join   LU_CATEGORY   a13
        on    (a12.CATEGORY_ID = a13.CATEGORY_ID))
        on    (a11.REGION_ID = a14.REGION_ID)
    group by   a11.REGION_ID,
       a12.CATEGORY_ID
      Both From clauses are functionally identical. This is by design -- the intent of this property is to change the From clause order only, to fit better with a particular database platform's SQL optimizer.

      If it is needed to change the behavior of outer joins, the VLDB properties pertaining to outer joins should be used:

      • Preserve all final pass result elements
      • Preserve all lookup table elements
      • Downward outer join
