Remove the "Layout" tab in a Document in MicroStrategy

Remove the "Layout" tab in a Report Services Document in MicroStrategy

In MicroStrategy Web 10.x, when using report services documents, there is a 'Layout' tab on top of the document even when there is only one layout in document, as shown below:

ACTION:

To remove the tab from being visible, follow these steps:

Go to design mode for the document where the 'Layout' tab is no longer desired and under the 'Tools' tab, select the 'Document Properties' option:
A new window will open. Select the 'Advanced' section under 'Document Properties' on the left pane, and make sure to uncheck the option for 'Show single layout tab' under the 'Layout' section as shown below:
Once the option is unchecked, click on the 'Apply' button. The user will now notice that the 'Layout' tab has been removed from view in all document modes:

Note: This option is set on an individual document level.
