Retrieve a list of user groups and the associated users in MicroStrategy

Retrieve a list of user groups and the associated users in MicroStrategy Developer 9.x

Although MicroStrategy Command Manager 9.x can be used to generate lists of all user groups and all users within a particular group, there is currently no way for it to retrieve a list of all groups and all of the users in each group. If such a list is desired, it can be created using the Project Documentation Wizard in MicroStrategy Desktop Developer 9.x.

Follow the steps below to create a list of all groups and the users in each group:

In MicroStrategy Developer 9.x, select 'Project Documentation' from the Tools menu to start the wizard.
Select any project that is in the project source that contains the users and groups and click Next.
Select only Configuration Objects for documentation.
Uncheck the 'Basic Properties' object category from the next screen, as shown below:
Then select only 'User Group' under the Configuration Objects section and only 'Groups' and 'Members' under the Definition section, as shown below:
Go through the rest of the wizard, and open the resulting documentation. After navigating down to the User Groups, the documentation should look similar to the following image:

This page shows every group, any child groups, and all members of each group.
